Wide Voltage IP67 Waterproof Switching Power Supply Constant Voltage Compact Size 1000W 24V36V48V LED Driver
| Luogo di origine | Guangdong, Cina |
|---|---|
| Marca | Miracle Bean |
| Certificazione | CE ROSH EMC |
| Numero di modello | XH-LPV-1000W |
| Quantità di ordine minimo | 1 pari |
| Prezzo | negotiate |
| Imballaggi particolari | Cartone animato o legno |
| Tempi di consegna | 5-15 giorni |
| Termini di pagamento | T/T, Unione Occidentale |
| Capacità di alimentazione | 10000pici al mese |
Contact me for free samples and coupons.
WhatsApp:0086 18588475571
wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xDettagli
| Classe IP | IP67/IP65 | Nome degli elementi | Alimentazione a LED |
|---|---|---|---|
| Materiale a guscio | Lega di alluminio | Temperatura operativa | -20 ° C a 60 ° C. |
| Dimensioni del prodotto | 265*120*56mm | Certificazioni | CE/FCC/ROHS |
| Potenza in USCITA | 1000 W | Colore | Argento |
| Protezione | Corto circuito/temperatura superiore/carico | Efficienza | 94% |
Descrizione di prodotto
Efficiency Efficiency Universal Outdoor 800W LED Power Supply Waterproof IP65/IP67 Constant Current LED Driver
Product Description
| Modle | XH-LPV-1000W |
| Output current range | 24V/36V/48V/60V |
| DC output power | 1000W |
| AC Input Current |
7.5A/230VAC |
| Store temperature and humidity | -40~+85°10-95% RH |
| Working temperature and humidity | -20~+60 centigrades 20-90% RH non-condensing(waterproof) |
| Dimesion |
265*120*56mm(L*W*H) |
| Efficiency |
94% |
| Weight |
2.75kg |
Description
The XH-LPV-1000W series is a waterproof AC-DC LED driver boasting constant voltage and constant power output, designed to work with an AC input voltage range of 180V to 264V. It offers versatile output voltage choices, including 24V, 36V, 48V, and 60V.
With a conversion efficiency of up to 94% and a fanless structure, the driver operates via natural air cooling, keeping its case temperature within -20℃ to +60℃. Thanks to its metal casing and high IP rating (IP65/IP67), it’s suitable for both indoor and outdoor use. It also incorporates a 105℃ long-life aluminum electrolytic capacitor for enhanced durability.
Equipped with full-range protection features and 5G vibration resistance, the XH-LPV-1000W adheres to safety standards like UL1012 and EN60950-1, while meeting the energy-saving demands of next-gen LED lighting. As a cost-effective solution, it fits a broad spectrum of LED lighting applications.
Features
- AC Input Voltage: Spans 180VAC to 264VAC
- Output Mode: Supports both constant voltage and constant power operation
- Protection Functions: Equipped with short circuit, overload, overvoltage, overtemperature protection, and other safety mechanisms
- Cooling Method: Employs natural air convection for heat dissipation
- Housing Design: Boasts an aluminum housing with a fully protective construction
- Protection Standard: Features a full potting process, meets IP65/IP67 protection levels, and is applicable for indoor and outdoor installation
- Applicable Environment: Suitable for dry, humid, and rain-exposed scenarios
- Quality Testing: Undergoes 100% full-load burn-in testing prior to delivery
- Core Advantages: Offers high efficiency, long service life, and superior reliability
- Warranty Service: Backed by a 3-year quality warranty
